How do you configure a network adapter in Linux?

Configuring a network adapter in Linux can vary based on the distribution and your specific needs. This article provides a comprehensive guide on how to configure a network adapter in Linux, ranging from basic configurations to advanced techniques.

Table of Contents

• Check the Current Network Configuration
• Configure a Static IP Address
• DHCP Configuration
• Configuring Hostname and DNS
• Network Manager CLI Tools
• Troubleshooting Network Issues

Check the Current Network Configuration

Before making any changes, you need to check the current network configuration. You can do this using several commands:

ifconfig

ip a

Both commands provide useful information such as the IP address, netmask, and the status of the network interfaces.

Configure a Static IP Address

To configure a static IP address, follow these steps:

Using the ifconfig Command

1. Edit the network interface configuration file, typically located at /etc/network/interfaces:

sudo nano /etc/network/interfaces

2. Add or modify the following lines:

iface eth0 inet static
address 192.168.1.100
netmask 255.255.255.0
gateway 192.168.1.1
dns-nameservers 8.8.8.8 8.8.4.4

3. Save the file and exit the text editor.
4. Restart the networking service:

sudo service networking restart

Using the nmcli Command

1. Show available connections:

nmcli con show

2. Modify the connection:

sudo nmcli con mod 'System eth0' ipv4.addresses '192.168.1.100/24' ipv4.gateway '192.168.1.1' ipv4.dns '8.8.8.8 8.8.4.4' ipv4.method 'manual'

3. Bring the connection up:

sudo nmcli con up 'System eth0'

DHCP Configuration

To use the DHCP configuration, edit the interface file:

sudo nano /etc/network/interfaces

Then, update the file with the following settings:

iface eth0 inet dhcp

Restart the networking service:

sudo service networking restart

Configuring Hostname and DNS

Setting the Hostname

1. Edit the hostname file:

sudo nano /etc/hostname

2. Replace the current hostname with the new hostname.
3. Edit the hosts file:

sudo nano /etc/hosts

4. Update the file by adding your new hostname:

127.0.1.1 your-new-hostname

Configuring DNS Servers

1. Edit the resolved.conf file:

sudo nano /etc/systemd/resolved.conf

2. Add or modify the DNS entries:

DNS=8.8.8.8 8.8.4.4

3. Restart the systemd-resolved service:

sudo systemctl restart systemd-resolved

Network Manager CLI Tools

Network Manager comes with several command-line tools that can facilitate network configuration:

• nmcli: A command-line client for NetworkManager
• nmtui: A text user interface for NetworkManager
• nmtui-connect: Tool to connect to a specific network

Using nmcli

• Show device status:

nmcli dev status

• List available Wi-Fi networks:

nmcli dev wifi list

• Connect to a Wi-Fi network:

nmcli dev wifi connect 'YourSSID' password 'YourPassword'

Using nmtui

1. Launch the nmtui interface:

sudo nmtui

2. Choose to Edit a Connection, Activate a Connection, or Set System Hostname.

Troubleshooting Network Issues

Network issues can arise due to misconfigurations or hardware problems. Here are steps to troubleshoot:

Check Interface Status

ifconfig

ip a

Ensure the interfaces are up and have IP addresses.

Restart Network Manager

sudo systemctl restart NetworkManager

Check Logs

journalctl -u NetworkManager

Review logs for any error messages.

Ping Tests

• Ping your gateway:

ping 192.168.1.1

• Ping an external address:

ping google.com

By following these steps, you can configure your network adapter in Linux successfully. Always ensure to backup configuration files before making changes.
